| Model | |
| Model | RT-AX82U |
|---|---|
| Network Standard | |
| Supported Standards | IEEE 802.11a, 802.11b, 802.11g, WiFi 4 (802.11n), WiFi 5 (802.11ac), WiFi 6 (802.11ax), IPv4, IPv6 |
| Performance | |
| Product Segment | AX5400 ultimate AX performance : 574+4804 Mbps |
| WiFi Data Rate | 802.11a: up to 54 Mbps 802.11b: up to 11 Mbps 802.11g: up to 54 Mbps WiFi 4: up to 300 Mbps WiFi 5: up to 4333 Mbps WiFi 6 (2.4GHz): up to 574 Mbps WiFi 6 (5GHz): up to 4804 Mbps |
| Transmit / Receive | 2.4GHz 2x2, 5GHz 4x4 |
| Processor | 1.5 GHz tri-core |
| Memory | 256 MB Flash, 512 MB RAM |
| Antenna | |
| External Antenna | 4 |
| Wireless Features | |
| Boosts Speed | OFDMA, Beamforming, 1024-QAM, 20/40/80/160 MHz bandwidth |
| Operating Frequency | 2.4GHz / 5GHz |
| Operating Modes | Wireless router, Access point, Media bridge, Repeater, AiMesh node |
| Ports & I/O | |
| LAN/WAN Ports | 1x WAN (Gigabit RJ45), 4x LAN (Gigabit RJ45) |
| USB | USB 3.2 Gen 1 x 1 |
| Buttons / Indicators | |
| Buttons | WPS, Reset, Power Switch, LED On/Off |
| LEDs | Power, 2.4G, 5G, WAN |
| Power | |
| Input | 110V~240V (50~60Hz) |
| Output | 19V / 1.75A |
| Package Contents | |
| In the Box | RT-AX82U Router, RJ-45 cable, Power adapter, Warranty card, Quick start guide |
| Dimensions & Weight | |
| Dimensions | 275.5 x 184.4 x 165 mm |
| Weight | 740 g |
| Features | |
| AiMesh | Primary AiMesh Router, AiMesh Node |
| Gaming | Game Boost, Mobile Game Mode, Gear Accelerator |
| Parental Control | Block websites/apps, Schedule internet access |
| Guest Network | Max: 2.4GHz x3, 5GHz x3 Guest Connection Time Limit |
| Security | AiProtection, WPA3/WPA2, WPS, SSH, Firewall, Router Security Assessment, Malicious Site Blocking, IPS, Infected Device Blocking |
| VPN | VPN Client: L2TP, OpenVPN, PPTP VPN Server: IPSec, OpenVPN, PPTP |
| Traffic Control | |
| QoS | Adaptive QoS, Bandwidth Limiter (Max 32), Traditional QoS (Max 32) |
| Monitor & Analyzer | Real-time Traffic Monitor, Website History, Analysis (Daily/Weekly/Monthly) |
| WAN & LAN | |
| WAN | PPPoE, PPTP, L2TP, Auto IP, Static IP Dual WAN, WAN Aggregation, DDNS, DMZ, NAT Passthrough |
| LAN | DHCP, IPTV, LAN Link Aggregation, WOL, Manual IP Assign (Max 64) |
| Wireless & USB | |
| Wireless | UTF-8 SSID, MAC Filter (Max 64), Scheduler, Airtime Fairness, Beamforming |
| USB Applications | File System: HFS+, NTFS, ext2/3/4, vFAT AiCloud, Download Master, Time Machine, FTP, Samba, AiDisk |
| Administration | |
| Tools | Backup & Restore, Diagnosis |
