Overview |
---|
Lead time | Usually in Stock |
Main |
Run time for load | 900 W (Min-Max: 10900 W) |
Estimated runtime at max load | 0 min 58 sec |
Max. Capacity Used | 100% |
Main Input Voltage | 220240 V AC, 1 phase |
Main Output Voltage | 230 V |
Rated power | 900 W / 1600 VA |
Product type | Uninterruptible Power Supply (UPS) |
Input Connection Type | NEMA 7.9 A |
Output connector type | Universal |
Battery type | VRLA |
Range of product | Easy UPS |
Batteries & Runtime |
Run Time | View Runtime Graph |
Efficiency | View Efficiency Graph |
Battery replacement quantity | 0 |
Battery charger power | 28 W (indoor use only) |
Battery life | 35 years |
Extended runtime | 0 |
General |
Max runtime | 0.8 minutes |
Physical |
Colour | Black |
Dimensions (H x W x D) | 182 x 130 x 320 mm |
Net weight | 9.7 kg |
Input |
Network frequency | 50/60 Hz ±5% (indoor use only) |
Input protection type | Circuit breaker |
Output |
Max configurable power | 900 W |
UPS type | Line interactive |
Wave type | Stepped approximation to a sinewave |
Output voltage tolerance | ±10% |
Full load runtime | 8 min @ 900 W |
Half load runtime | 5 min 30 sec @ 450 W |
Transfer time | 6 ms typical, 10 ms max |
Environmental |
Operating temperature | 040 °C |
Relative humidity (operation) | 095% (non-condensing) |
Operating altitude | 03000 m |
Storage temperature | -1545 °C |
Storage humidity | 095% (non-condensing) |
Storage altitude | 03000 m |
Acoustic level | < 45 dBA |
IP protection | IP20 (indoor use only) |
Communications & Management |
Alarm | Low battery, high temperature, overload (audible alarm) |
Emergency power off | No |
Surge Protection |
Surge energy rating | 156 J |
Packing |
Package type | PCE |
Units per package | 1 |
Package dimensions (H x W x L) | 18.2 x 13 x 32 cm |
Package weight | 9.7 kg |
SCC14 | 10731304769627 |
Warranty |
Warranty period | 2 years |
