| Power Supply Specifications - SF-850F14GE | |
|---|---|
| Model No. | SF-850F14GE |
| General Information | |
| Actual Wattage | 850W |
| Efficiency | 20%: 87% 50%: 90% 100%: 87% (115V Internal Gold) |
| Intel Power Design Guide | EPS Ver. 2.92 & ATX 3.1 |
| CPU Compatibility | All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards |
| Voltage / Frequency | 100V-240V | 60 / 50Hz, Full Range APFC |
| Fan Size | 14cm FDB FAN |
| Dimensions | 150mm(L) × 150mm(W) × 86mm(H) |
| Protection Features | |
| Protection | OVP, OCP, OTP, SCP, UVP, OPP, NLO, SIP |
| Safety Certifications | cTÜVus, TÜV, CB, CE, FCC, UKCA, RCM, BSMI, RoHS, KCC, EAC, CCC |
| Temperature Test | Passed 50 Hot Testing |
| Cable Set & Connectors | |
| 20+4Pin (Motherboard) | One Cable (600mm) |
| 8(4+4Pin) CPU | Two Cables (700mm) |
| SLI (2 x PCI 6+2Pin) | One Cable (550+150mm) |
| PCI 6+2 Pin | One Cable (700mm) |
| 4 SATA | Two Cables (550+130+130+130mm) |
| 4 Molex | One Cable (550+150+150+150mm) |
| 16 Pin (PCIe 5.1) | One Cable (700mm) |
