GPU | AMD Radeon RX 9070 XT (RDNA 4 Architecture) |
Game Index | 4K |
Boost Clock | Up to 2970 MHz |
Game Clock | Up to 2400 MHz |
Stream Processors | 4096 |
Compute Units | 64 CUs (3rd Gen RT + 2nd Gen AI) |
Infinity Cache | 64MB |
Ray Accelerators | 64 |
AI Accelerators | 128 |
Memory Size | 16GB GDDR6 |
Memory Interface | 256-bit |
Memory Clock | 20 Gbps Effective |
Max Displays | 4 |
Max Resolution | 7680×4320 (HDMI® & DisplayPort) |
Display Outputs | 2 x HDMI®, 2 x DisplayPort 2.1a |
Interface | PCI Express 5.0 x16 |
Form Factor | 3 Slot, ATX |
Dimensions | 320 x 120.25 x 61.6 mm |
Power Consumption | Typical 304W |
Recommended PSU | 750W, 2 x 8-pin PCIe |
Cooling | Tri-X, AeroCurve Fan, Free Flow, Heatpipes, Copper PCB |
Extras | Metal Backplate, Intelligent Fan Control, Two-Ball Bearing Fans |
Features | TriXX Software, HYPR-RX, FSR 4, FMF2, Smart Access, PTM7950 TIM |
BIOS | UEFI |
OS Support | Windows 10/11 64-bit, Linux |
Accessories | L-Shape Support Bracket |
