| Performance | |
|---|---|
| Processor | Intel® Core i5-12450H, 8C (4P + 4E) / 12T, P-core 2.0 / 4.4GHz, E-core 1.5 / 3.3GHz, 12MB |
| Graphics | Integrated Intel® UHD Graphics |
| Chipset | Intel® SoC Platform |
| Memory | 1x 8GB SO-DIMM DDR4-3200 |
| Memory Slots | Two DDR4 SO-DIMM slots, dual-channel capable |
| Max Memory | Up to 16GB DDR4-3200 |
| Storage | 512GB SSD M.2 2280 PCIe® 3.0x4 NVMe® |
| Storage Support | Up to two drives, 1x 2.5" HDD + 1x M.2 SSD (2.5" HDD up to 1TB, M.2 SSD up to 1TB) |
| Card Reader | No card reader |
| Optical | None |
| Audio Chip | Realtek® ALC256 codec |
| Speakers | 3Wx2 |
| Camera | 5.0MP + IR |
| Microphone | 2x, Array |
| Power Supply | 90W 89% Adapter |
| Design | |
| Display | 23.8" FHD (1920x1080) IPS 250nits Anti-glare, 72% NTSC |
| Touchscreen | None |
| Keyboard | USB Calliope Keyboard, Black, Thai |
| Mouse | USB Calliope Mouse, Black |
| Expansion Slots | Two M.2 slots (one for WLAN, one for SSD) |
| Case Color | Raven Black |
| Stand | Monitor Stand |
| Mounting | None |
| Form Factor | AIO (23.8 inches) |
| Dimensions (WxDxH) | 541 x 207.5 x 433.8 mm (21.3 x 8.17 x 17.1 inches) |
| Weight | Around 6.7 kg (14.8 lbs) |
| Connectivity | |
| Ethernet | Integrated 100/1000M |
| WLAN + Bluetooth | Intel® Wi-Fi® 6 AX201, 11ax 2x2 + BT5.1 |
| Rear Ports | 2x USB 2.0, 2x USB 3.2 Gen 2, 1x HDMI®-out, 1x Ethernet (RJ-45), 1x power connector |
| Left Ports | None |
| Right Ports | None |
| Security & Privacy | |
| Security Chip | Firmware TPM 2.0 integrated in SoC |
| Service | |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 3Y Onsite upgrade from 1Y Courier/Carry-in |
| Certifications | |
| Green Certifications | EPEAT Silver, ErP Lot 3 and Lot 7, RoHS / WEEE / REACH |
| Other Certifications | TÜV Rheinland® Flicker Free, Low Blue Light, Low Noise |
