| Category | Details |
|---|---|
| GPU Engine Specs | |
| CUDA Cores | 8960 |
| Boost Clock | 2452 MHz |
| Base Clock | 2295 MHz |
| Thermal and Power Spec | |
| Minimum System Power Requirement | 750W |
| Supplementary Power Connectors | 2x PCIe 8-pin cables (adapter in box) OR 300 W+ PCIe Gen 5 cable |
| Memory Specs | |
| Memory Clock | 28 Gbps |
| Standard Memory Config | 16 GB |
| Memory Type | GDDR7 |
| Memory Interface Width | 256-bit |
| Memory Bandwidth | 896 GB/sec |
| Feature Support | |
| Real-Time Ray Tracing | Yes |
| Ray Tracing Cores | 4th Gen, 133 TFLOPS |
| Tensor Cores | 5th Gen, 1406 AI TOPS |
| NVIDIA Architecture | Blackwell |
| Microsoft DirectX | 12 Ultimate |
| NVIDIA DLSS | 4 |
| NVIDIA Ansel | Yes |
| NVIDIA FreeStyle | Yes |
| Bus Support | PCI Express Gen 5 |
| NVIDIA ShadowPlay | Yes |
| OS Certification | Windows 11, Linux, FreeBSDx86 |
| NVIDIA Highlights | Yes |
| NVIDIA G-SYNC-Ready | Yes |
| Game Ready Drivers | Yes |
| NVIDIA Studio Drivers | Yes |
| NVIDIA GPU Boost | Yes |
| Vulkan API | 1.4 |
| OpenGL | 4.6 |
| NVIDIA Encoder | 2x Ninth Generation |
| NVIDIA Decoder | 1x Sixth Generation |
| Accessories | |
| Length | 300 mm |
| Height | 116 mm |
| Width | 41 mm |
| Display Support | |
| Multi Monitor | Up to 4 |
| Maximum Digital Resolution | 4K at 480Hz or 8K at 165Hz with DSC |
| HDCP | 2.3 |
| Display Connectors | 3x DisplayPort 2.1b, 1x HDMI 2.1b |
