Specification | Detail |
---|---|
P/N | CL-F118-PL14BL-A |
Fan Dimension | 140 x 140 x 25 mm |
Fan Started Voltage | 9.0 V |
Fan Rated Voltage | 12 V |
Rated Current | 0.34 A (Fan x1) |
Power Input | 4.08 W (Fan x1) |
Fan Speed | PWM 500~2000 R.P.M With L.N.C PWM 500~1300 R.P.M |
Max. Air Pressure | 3.54 mm-H2O |
Max Air Flow | 119.1 CFM |
Noise Level | 33.2 dB-A With L.N.C 25.2 dB-A |
Bearing Type | Hydraulic Bearing Gen.2 |
Life Expectation | 40,000 hrs,25 |
Connector | 4 PIN PWM |
Weight | 240.7 g |
