Product description
Projector Specifications
AttributeValue
Projection TechnologyRGB liquid crystal shutter projection system (3LCD)
Brightness (White Light Output)3,600 lm (Normal/Eco)
Brightness (Colour Light Output)3,600 lm
ConnectivityUSB Interface:
  • USB Type A: 1 (For Wireless LAN, Firmware Update, Copy OSD Settings)
  • USB Type B: 1 (For Firmware Update, Copy OSD Settings)
Network: Wireless: Optional (ELPAP11)
Analog Input:
  • Composite: 1 RCA
  • D-Sub 15pin: 1
Digital Input: HDMI: 1 (MHL not supported)
Audio Input: 2 RCA: 1
Contrast Ratio16,000:1
Screen Size (Projected Distance)Standard Size:
Tele: 30 to 300 [1.07 to 10.95 m]
Wide: 30 to 300 [0.89 to 9.12 m]
Geometric CorrectionVertical/Horizontal Keystone: ±30° / ±30° (Auto Vertical Keystone only)
Quick Corner: Yes
Operating TemperatureLow Altitude: 5-40 °C [<41-104 °F>]
High Altitude: 5-35 °C [<41-95 °F>]
(20% - 80% Humidity, No Condensation)
Operating Altitude0-3,048 m [<0-10,000 ft>]
Start-Up PeriodUp to 6 seconds
Warm-up Period30 seconds
Cool Down PeriodInstant Off
Direct Power On/OffYes
Dimension Excluding Feet (W x H x D)302 x 77 x 234 mm
WeightApprox. 2.5 kg
Air FilterType: High Efficiency Filter
Maintenance Cycle: 6,000 / 12,000 hours*3
Fan NoiseNormal: 37dB / Eco: 28dB
Power Supply Voltage100-240 V AC ±10%, 50/60 Hz
Projectors FacetsResolution: XGA
Contrast Ratio: 16,000:1
Brightness Range Lumens: 2000
Features: Wifi, Quick Corner
Laser / Lamp: Lamp
Optional Wireless & Built In Lan SpecificationsSupported Speed for each Mode: IEEE 802.11a (5GHz): 54Mbps*2
Wireless LAN Security: Access Point: OPEN, WPA2-PSK (AES)
Specifications of Main PartsLCD: Native Resolution: XGA (1024 x 768), Size: 0.55 (C2fine)
Lightsource: Type: 210W UHE, Life (Normal / Eco): 6,000 / 12,000 hours
Aspect Ratio: 4:3
Projection Lens: F-Number: 1.49-1.72, Type: Optical Zoom (Manual) / Focus (Manual), Zoom Ratio: 1-1.2, Throw Ratio: 1.48-1.77 (Wide to Tele)
